Electric 3 Wheel Pickup Truck
The electric 3 wheel truck is available in a cargo truck, or as a pickup truck. It can be used as a small pickup, or multifunctional three wheeler because the rear half is an open container with no roof and three side openable baffles, making it easy to load and unload cargo.
Technical specifications
| Brand | RAP | |
| Model | BANGE | BANGE II |
| Category | L2e-U | L5e-B |
| Loading mass | 250Kg | |
| Motor type | AC asynchronous motor | PMSM |
| Rated power | 3.7Kw | 5.0Kw |
| Rated torque | 7.8Nm | 10.6Nm |
| Battery type | LiFePO₄ | |
| Rated battery voltage | 73.6V | |
| Battery cell capacity | 100Ah | |
| Battery capacity | 7.36 kWh | |
| Charger type | On board | |
| Charging voltage | 205-265V | |
| Tilting system | LH/RH 18 degree | |
| Charging time | 20%-80%: 1.5 h; 0%-100%: 3.5h | |
| Front suspension | Hydraulic shock absorption fork | |
| Rear suspension | Integral damping | |
| Brake system | LH/RH hand brake | LH hand brake/Brake pedal |
| Brake type | Hydraulic front/rear disc | |
| Parking type | Mechanical handle brake rear wheel | |
| Tire | Front :110/90-12; Rear:135/70r12 | |
| Max. speed | 45km/h | 60km/h |
| Climbing capacity, full load | 20% | |
| Range | Up to 120Km | |
| Fault detection | / | OBD |
| Specifications |
|
|
| BOX | Type | Honeycomb panel |
| Capacity L | 1600L | |
| Color | Customizable | |
| Packing | 4 units-CBU/20GP; 8 units-CBU/40HC; 16 units-SKD/40HC | |
